Factory Lead Time

10 Weeks

Mounting Type

Surface Mount

Package / Case

8-SMD Module, 5 Leads

Number of Pins

5

Weight

1g

Voltage - Input (Nom)

3.3V

Power Dissipation (Max)

250mW

Operating Temperature

-40°C~100°C

Packaging

Tube

Series

ECONOLINE R0.25S (0.25W)

Size / Dimension

0.49Lx0.42W x 0.28 H 12.8mmx10.7mmx7.0mm

JESD-609 Code

e1

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

5

ECCN Code

EAR99

Type

Isolated Module

Terminal Finish

Tin/Silver/Copper (Sn/Ag/Cu)

Applications

ITE (Commercial)

Terminal Position

DUAL

Terminal Form

GULL WING

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Depth

10.7mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Number of Outputs

1

Qualification Status

Not Qualified

Efficiency

60 ~ 70%

Voltage - Isolation

1kV

Voltage - Input (Max)

3.6V

Voltage - Input (Min)

3V

Trim/Adjustable Output

NO

Current - Output (Max)

50mA

Current - Output

50mA

Output Power

250mW

Max Output Voltage

5V

Voltage - Output

5V

Current - Output 1

50mA

Nominal Input Voltage

3.3V

Isolation

Isolated

Features

SCP

Height

7mm

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
